Name: JBL VMA 1120 5 input x 60/120/240W output Mixer/Amplifiers
Brand: sevenplus
SKU: XM1800S-1-3-1-1-1-1-1-1-4-2-1-1-1-1-1-1-1-2-1-1-2-1-1-2-1-1-1-1-1-1-1-2-1-1-1-1-1-1-1-1-1-1-1-1-1-2-1
Price: 2857.5 AED
Availability: InStock
Rating: 5 (1 reviews)

JBL VMA 1120 5 input x 60/120/240W output Mixer/Amplifiers

AED 2,857.50

Max Output Power per Channel:	into 4 Ω or 8 Ω; 1kHz, ≤ 0.5% THD – VMA160: 60W VMA1120: 120W VMA1240: 240W
Insertion Loss:	(70V & 100V outputs) 1dB maximum
Number of Inputs:	5
Number of Outputs:	1
Tone Controls:	(Bass and Treble non-detented potentiometers on each channel) Bass +/-14dB @ 50Hz; Treble +/-14dB @10kHz
Input Sensitivity:	(to obtain full rated power into 8 Ω load) Mic Input: 5.5mVRMS Line Input: 1.3VRMS RCA Input (stereo in): 130mVRMS
Frequency Response:	(measured at 2.83VRMS into rated load impedance at any output) 4/8 Ω Output: 20Hz – 20kHz, +/-2dB; 70V/100V Outputs: 80Hz – 15kHz +/-3dB
Total Harmonic Distortion (THD):	(measured at 2.83VRMS into rated load impedance at any output) Power Amp Output: <0.5%, 20Hz – 20kHz
Signal to Noise Ratio:	(Ref. Rated Power, mixer levels @ min., master volume @ max. A-weighted) >76dB
Input Impedance:	(nominal) Mic: 400 Ω Line: 20 kΩ (balanced) RCA: 50 kΩ
Phantom Power:	27VDC
Crosstalk:	(reference rated power, volume at mid position, 1kHz) -70 dB
Nominal AC Line Voltages:	100V, 120V, 220V, 220-240V, 50/60 Hz
Minimum Load Impedance:	(Low Impedance Output, 70V Output, 100V Output) VMA160: 4 Ω, 80 Ω,160 Ω VMA1120: 4 Ω, 40 Ω, 80 Ω VMA1240: 4 Ω, 20 Ω, 40 Ω
Operating Temperature/Humidity:	0°C to 35°C @ 95% R.H. (non-condensing)
Storage Temperature:	-20°C to 85°C
Net Weight:	VMA160: 19.4 lb (8.8 kg) VMA1120: 20.2 lb (9.2 kg) VMA1240: 25.5 lb (11.6 kg)
Dimensions:	Width: 17.0 in. (432 mm) Depth: 16.3 in. (415 mm) Height: 3.5 in. (88 mm)
Shipping Weight:	VMA160: 24.6 lb (11.2 kg) VMA1120: 25.5 lb (11.6 kg) VMA1240: 30.8 lb (14 kg)

ENQUIRE NOW

Delivery

For all cash on delivery orders, the delivery will be initiated only after confirming the order with the customer via call from our sales team.
In the case of card payment or bank transfer, we will proceed with the delivery only once the money is credited in our bank account.
Within city limits of Dubai and Sharjah emirates products ordered will be delivered within 1-2 days. Delivery schedule for other emirates will be completed within 2-3 days.
Free delivery for products purchased above AED 599.
We charge a nominal fee for the same day delivery. Charges are mentioned at the time of checkout.
The order for the items eligible for delivery should be placed before 12pm to get the items delivered the same day or else the delivery will be scheduled for the following day provided it’s a working day.
Delivery is not applicable on Sundays or on any public holidays.

Return And Refund Policy

Refund or exchange of the purchased product is subject to the following terms and conditions:>

1) Products must be returned within 7 days from the date of delivery received, the product must be in good and unused condition (must be unopened and in original packaging).

2) Refund to be requested with a valid reason (damaged on delivery, manufacturing defect, incorrect product)

3) Seven Plus team will inspect returned items at the collection point. (Refund will not be accepted if anything missing, used or not placed in the original packaging).

4) In the case a faulty or incorrect item has been delivered, Seven Plus will cover the return shipping costs (contact info@sevenplusuae.com)

All Card payments will be refunded to the bank account within 14 working days.

Warranty Returns/Repair Service contact : info@sevenplusuae.com for more information

Products in Promotion or Special Offer are Non-refundable or non-exchangeable
1) Services completed (Delivery, installation and labour) are Non-refundable.

Help

Give us a shout if you have any other questions and/or concerns.
Email: info@sevenplusuae.com
Phone: +971 50 700 1176
Phone: +971 50 726 3054

SKU: XM1800S-1-3-1-1-1-1-1-1-4-2-1-1-1-1-1-1-1-2-1-1-2-1-1-2-1-1-1-1-1-1-1-2-1-1-1-1-1-1-1-1-1-1-1-1-1-2-1 Categories: All Products Brand JBL PA System Installation Tags: amplifier mixer

Free

Worldwide
Shopping

100%

Guaranteed
Satisfaction

30 Days

Guaranteed
Money Back

VMA 1120: (5) input channel x (1) 120W output channel Mixer/Amplifier

Features

5 inputs with 1 output of 60, 120, or 240-watts of power
Independent bass and treble controls for each output channel
100V and 70V output, or 4Ω/8Ω
Paging Chime, and Priority muting
Works with JBL CSR-V wall controllers
Balanced mic/line inputs; RCA (.775V) inputs
Rack mounting hardware included
